Specifications
Table 1. Dimensions
|
Measurements |
Width |
Depth |
Height |
|
|
19.0 in. |
28.7 in. |
24.0 in. |
The maximum configuration weight is: 96 kg (210 lb)
Table 2. Electrical
|
Electrical characteristics |
Properties |
|
kVA (maximum) |
0.862 |
|
Rated voltage and frequency |
100-127/200-240 V ac at 50-60 plus or minus 0.5 Hz |
|
Thermal output (maximum) |
2867 Btu/hr |
|
Power requirements (maximum) |
840 W |
|
Power factor |
0.95 |
|
Inrush current |
90 A |
|
Leakage current (maximum) |
3.5 mA |
|
Phase |
1 |
|
Compatible plug types |
45,
6,
10,
18,
19,
22,
23,
24,
25,
32,
34 |
|
Power cord length |
1.8 m (6 ft) (U.S. only), 4.3 m (14 ft) |
Table 3. Temperature requirements
|
Operating |
Nonoperating |
|
10 - 38°C (50 - 100.4°F) |
1 - 60°C (33.8 - 140°F) |
Table 4. Environment requirements
|
Environment |
Operating |
Nonoperating |
|
Noncondensing humidity |
8 - 80% |
8 - 80% |
|
Wet bulb temperature |
22.8 °C (73 °F) |
27 °C (80.6 °F) |
|
Maximum altitude |
3048m (10 000 ft) |
|
Table 6. Service clearances
|
Front |
Back |
Sides2 |
Top2 |
|
30 in. |
30 in. |
30 in. |
30 in. |
Table 7. Notes
Notes:
- For a description of noise emission
values, see Acoustics.
- Side and top clearances are optional
during operation.
|
Expansion Units
- The 5074, 5079, 507, or 5078 expansion unit is available with model
9406-820.
